Dynamic DNS with API Gateway and Route53 in place of Lambda

A few of the CorpInfo cloud engineers were chatting about making their own Dynamic DNS on Amazon Web Services (AWS) for some personal projects. As we got to talking I realized that although Lambda was the go-to technology, it’s not really needed. One of the least used capabilities of API Gateway is the ability to call the AWS API directly, effectively turning an API Gateway HTTP request into an AWS API request.

You certainly wouldn’t want to give the world access to your AWS account so we’ll make sure to keep the system locked down – but as you’ll see in this walk through, you do not need Lambda in order to create a simple Dynamic DNS in Route 53.

We’re going to assume you already have a domain hosted in Route 53. For our example, we’ll use acme.local as the domain name.

Step 1 – Create your API Gateway and resource

  • Create your API Gateway and give it a description. I’ve called mine DynamicDNS.
  • Create the resource: {zone_id}. For this exercise, I’m using a little bit of security through obscurity by requiring the Route 53 Zone Id in the url path. We’ll use the https://api_gw_url/route53_zone_id as the URL for updating.

Step 2 – Create the Method

For my uses, I want the simplest HTTP request possible as I want to be able to use this anywhere. We’ll create a GET request and map the request to the AWS Service: Route 53. This is where all of the magic happens.

Steps to take:

  • Create a GET request for the /{zone_id} resource.
  • Set it to AWS Service.
  • Set the Region to whatever you want (we’ll use us-west-2 but it doesn’t matter with Route53).
  • Set the service to Route 53.
  • Leave the AWS Subdomain blank.
  • Set the HTTP Method to POST. This is the method that the AWS service API is expecting. You can read more about it here: http://docs.aws.amazon.com/Route53/latest/APIReference/API_ChangeResourceRecordSets.html.
  • We’ll need to use a custom path in order to use the {zone_id} variable, so set Action Type to Use path override.
  • Reading the API docs linked in step 6, you’ll notice we need to ultimately use the path /2013-04-01/hostedzone/<Id>/rrset/, so we’ll set the Path Override to: /2013-04-01/hostedzone/{hosted_zone_id}/rrset/. I’ll explain why we used {hosted_zone_id} instead of {zone_id} a bit further down in this article.
  • Give it an IAM role. I’ve blocked out my IAM role in the screenshot as I don’t want to show our account number, but the IAM role will need the following trust relationship and role:

Trust Relationship:

{
  "Version": "2012-10-17",
  "Statement": [
    {
      "Sid": "",
      "Effect": "Allow",
      "Principal": {
        "Service": "apigateway.amazonaws.com"
      },
      "Action": "sts:AssumeRole"
    }
  ]
}

Role:

{
  "Version": "2012-10-17",
  "Statement": [
    {
      "Sid": "Stmt1487876360000",
      "Effect": "Allow",
      "Action": [
        "route53:ChangeResourceRecordSets"
      ],
      "Resource": [
        "arn:aws:route53:::hostedzone/Z1BZA5RDXLSXJ1"
      ]
    }
  ]
}

Note: make sure to change the actual Zone ID above. You’ll want to replace Z1BZA5RDXLSXJ1 with your Zone ID!

Step 3 – Configure Body Mapping Templates

We still have more work to do with the method as it will not send the Route 53 API any actual data.

  • Click on the GET Method on the left panel under Resources.
  • Click on the Integration Request header.
  • Scroll down to Body Mapping Templates and expand it.
  • Change the Request body passthrough to Never – this will prevent any data from passing into the AWS API. I feel this is the single most important thing you can do to secure your AWS account for this exercise! We’ll discuss more about this below.
  • Create a template for application/json. The reason we create this is application/json is the default Content Type for API Gateway. If we do not specify this, a standard curl request will not have a content type and therefore will fail.
  • In the text box near the bottom, we’ll insert our XML payload for the Route 53 API POST call:
<ChangeResourceRecordSetsRequest xmlns="https://route53.amazonaws.com/doc/2013-04-01/">
    <ChangeBatch>
        <Changes>
            <Change>
                <Action>UPSERT</Action>
                <ResourceRecordSet>
                    <Name>myddns.acme.local</Name>
                    <Type>A</Type>
                    <TTL>60</TTL>
                    <ResourceRecords>
                        <ResourceRecord>
                            <Value>$context.identity.sourceIp</Value>
                        </ResourceRecord>
                    </ResourceRecords>
                </ResourceRecordSet>
            </Change>
        </Changes>
    </ChangeBatch>
</ChangeResourceRecordSetsRequest>

Please note: you’ll need to change the name of the record you want to update. As stated above, we’re using acme.local for this article. I selected myddns as the record to create/update.

The magic of the dynamic DNS system happens on the <Value> line: $context.identity.sourceIp is mapped to the client’s IP address. Which means the DNS record will be updated with whatever client/external IP address API Gateway sees.

Regarding the Request body passthrough and security

As noted above, setting the Request body passthrough to Never is the best thing you can do for securing your AWS Service proxy. It’s not as big of a requirement with a GET method like we’ve created because GET’s do not allow for payloads. But say you created a POST or PUT method (both of which allow body data to be passed in) and selected the top option When no template matches the request Content-Type header. If someone were to POST to your API Gateway URL with a Content-Type you had not specified (eg: application/scriptkiddie) their entire payload would be passed on to the AWS Service. Which means they can send in their own XML and completely override yours.

Setting this to Never forces your payload to be the only payload that ever gets delivered to the AWS API.

Step 4 – Use the right Content-Type for the API Call

When you make a request to API Gateway, the content type you specify gets passed through to the Integration (in this case, our Integration is the Route 53 API). If you do not specify a Content Type, API Gateway sets your Content-Type header to application/json. This is a problem as we need to post to the Route 53 API as application/xml! So we’ll hardcode that in the HTTP Headers:
1. Expand the HTTP Headers section (just above the Body Mapping Templates).
2. Create a new HTTP Header and set the Name to: Content-Type.
3. Set the Mapped from to: 'application/xml' – Note: the single apostrophe’s are required!

Creating the HTTP Header with the apostrophes

HTTP Header created with the apostrophes

Step 5 – Configure {zone_id}

Remember in step 1 we created the /{zone_id} resource? Well now we’ll configure it. Since I don’t like to use the same variable name for two different services, we’ll convert {zone_id} to {hosted_zone_id}:
1. Expand URL Path Parameters section.
2. Create a new path with the Name of hosted_zone_id.
3. Set the Mapped from to: method.request.path.zone_id. This is where we utilize zone_id from the original resource path and map it to {hosted_zone_id} in the Path override setting.

Step 6 – Deploy

At this point, you can deploy your newly configured API Gateway. I used a stage called ddns but you can call it whatever you like.

You might think “hey, shouldn’t we test this first?” and while API Gateway has a great test feature, the test is not great for us as it’ll set our caller IP to a string – which will not work with DNS as we’re setting a record. So we’ll have to rely on curl to tell us if we’re working or not. Remember you’ll need your Zone ID from Route 53 in order to update DNS. The url format is:

https://your_api_gw_url/stage_name/zone_id

For my system, it ended up being: https://c3y150djkh.execute-api.us-west-2.amazonaws.com/ddns/ZICXXN1DR8UXO

On a successful GET request, you’ll get a 200 response code as well as the ChangeInfo response. At this point, your system is working. You can verify it by waiting (up to) 60 seconds and then checking your Route 53 console:

(Optional) Step 7 – Secure output

If you do not want to see the output of your Route 53 API call, you can adjust the data to just be empty:
1. Go to the GET Method -> Integration Response.
2. Expand the 200 Method Response status line (most likely the only one there).
3. Expand Body Mapping Templates.
4. Click on application/json.
5. Select Empty from the Generate template pulldown – this will fill in the Empty template into the textarea below.
6. Click the Save button at the bottom.
7. Redeploy your API.

(Optional) Step 8 – Additional Security

While we wont go into detail, you can optionally add additional security by adding an API Key to your method. There’s plenty of documentation on how to do this. Just remember that you’ll need to add the x-api-key header. So you’d end up with a curl request like this:

curl \
 -H "x-api-key: hzYAVO9Sg98nsNh81M84O2kyXVy6K1xwHD8" \
 'https://c3y150djkh.execute-api.us-west-2.amazonaws.com/ddns/ZICXXN1DR8UXO'

We’ll leave this step as an exercise for you!
